Fonestar | SCT-600 – Simultaneous interpretation transmitter
Datasheet: SCT-600
Simultaneous interpretation system for up to 5 languages with transmission via IR radiators. Allows connection of up to 6 translation desks. High sound quality without interference with lighting systems.
| FEATURES: | Transmitter of the SCT simultaneous translation system. Up to 5 languages, in addition to the original language. Connection of up to 10 SCT-61M or SCT-122M microphones in cascade. Auto output volume control. Transmission of the base channel (Channel 0) on the channel that the translator microphone is switched off. Built in compliance with IEC 60914 Conference Systems and IEC 61603-7 Transmission Systems standards. |
| RESPONSE: | 100-14,000 Hz |
| INDICATORS: | Output level in each channel |
| INPUTS: | 6 lines, RCA 18,000 Ω 2 V |
| OUTPUTS: | 6 lines, RCA 600 Ω 1 V 2 radiators, BNC 50 Ω 2 interpretation units, DB25 |
| S/N RATIO: | >75 dB |
| POWER SUPPLY: | 110-240 V AC, 40 W |
| DIMENSIONS: | 483 x 89 x 390 mm depth |
| WEIGHT: | 7 kg |
| ACCESSORIES: | 10 m interconnection cable for interpretation units, DB25 2 x audio cables, 6.3 mm mono jack to RCA |
